INSTRUMENT CIE., LTD DE DONGGUAN YUYANG
Fabricant de bonne qualité de la Chine d'équipement d'essai
 |
| Lieu d'origine: | La Chine |
| Nom de marque: | YUYANG |
| Certification: | ISO5470 |
| Numéro de modèle: | YY833 |
| Quantité de commande min: | 1 |
|---|---|
| Prix: | negotiation |
| Détails d'emballage: | Boîte en bois |
| Délai de livraison: | 1-3 jours de travail |
| Conditions de paiement: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Capacité d'approvisionnement: | 500 ENSEMBLES PAR MOIS |
| température ambiante de tableau noir: | ℃ de la température ambiante 30 | + ℃ 80 | Matériel de Shell: | acier inoxydable 304/revêtement |
|---|---|---|---|
| Source lumineuse :: | 1,8 kilowatts | Poids net :: | 110 kilogrammes |
| Dimensions hors-tout: | 925 * 487 * 487 millimètres | Puissance: | C.A. 220V/50HZ |
| Surligner: | Chambre d'essai de choc thermique,Chambre d'essai à l'embrun salin |
||
Temperature And Humidity Chamber Sand And Dust Chamber With LED Light
Description:
Xenon Aging Chamber Environment Accelerated Aging Chamber is analogue terrestrial solar radiation environment, widely used to determine the electrical, electronic products shell, leather and other light on the atmospheric environment adaptability; also be used to examine the effect of solar radiation on the ground equipment and components produced (thermal, mechanical, , chemical, electrical, etc.)
Structural characteristics:
A variety of alternative filtration system.
Water spray function.
Relative humidity control.
Chamber air temperature control system.
Irregularly shaped sample holder.
Cheap xenon arc lamps.
Xenon lamp aging test instrument easy to install and easy to use and basically no routine maintenance.
Xenon arc lamp life depends on the level of irradiance used, general lamp life of 1600 hours. Lamp replacement convenient, long-lasting xenon lamp aging tester filter to maintain the required spectrum to provide protection.
Specifications:
| light source | 1.8 KW original Q - Lab import air cooled xenon lamp or 1.8 KW domestic xenon lamp (normal life 1500 hours) |
| filters | filters or the sun glass filter (optional) |
| effective exposure area | 1000 cm2 (a 150 x 70 mm model 9) |
| light irradiance range | 30 w/m2 ~ 100 w/m2 (300 nm to 400 nm) Or 0.35 W/m2 ~ 0.7 W/m2 (@ 340 nm) Or 0.5 W/m2 ~ 2.1 W/m2 (@ 420 nm) |
| blackboard temperature range | room temperature 30 ℃ ~ + 80 ℃ |
| shell material | stainless steel 304 / coating |
| overall dimensions | 925 * 487 * 487 mm (length x width x height) |
| net weight | 110 kg (including packaging wooden box 140 kg) |
| power supply | 220 v, 50/60 hz;Maximum current 12 A |
